Mini Flush-Mount RFID Reader PP-22｜Multi-Card Compatibility & Reading Performance Verification (Customized Sample Test)

In industrial access control and equipment integration applications, RFID readers must balance compact installation requirements with stable and reliable reading performance.
The PP-22 mini flush-mount RFID reader is designed for such scenarios, delivering practical reading capability while maintaining a compact form factor suitable for space-limited installations.
This video documents a customized sample verification process for a specific customer project. Prior to mass production, the R&D team produced customized samples and conducted functional verification under practical operating conditions. One customization requirement in this project was an enhanced buzzer alert when a card is successfully detected, improving operational feedback in designated environments.


Test Procedure & Video Overview

The video demonstrates reading tests using different card types, including DESFire, MIFARE, and NFC cards. Due to varying card characteristics, actual reading distances may differ among card types.
This test does not focus on comparing precise distance values, but rather verifies stable reading response and correct feedback under fixed test conditions, ensuring that the customized PP-22 design performs reliably as intended.


Test Purpose & Application Value

Sample-stage verification helps system integrators and project engineers assess product feasibility early in the design phase, reducing risks during mass production and system deployment.
This testing approach is particularly suitable for industrial access control systems, control panel integrations, and OEM / ODM projects requiring functional customization, serving as a reliable reference before full-scale production.

※Mifare is a registered trademark of NXP B.V.
Mifare DESFire is a registered trademark of NXP B.V.
Mifare Ultralight is a registered trademark of NXP B.V.
FeliCa is a trademark of Sony Corporation.
